IV. |
FIBRE OPTIC SENSORS: |
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
SENSOR UNIT MODEL : BF-4R |
|
|
|
|
|
|
Light Source color |
|
: Red |
|
|
|
|
|
Power Source |
|
: 12 to 24VDC ± 10% |
|
|
|
|
Sensing Output |
: NPN Transistor - open collector |
|
|
|
|
|
Sink Current: Max 100mA Max. 30VDC |
|
|
|
|
|
With short circuit protection |
|
|
|
Self Diagnostic output |
: NPN Transistor open collector |
|
|
|
50mA 30VDC Max. Response Time |
: Less than 0.5ms |
|
|
|
|
Output operation |
: Light-ON/Dark-ON selector |
|
|
|
Operation Indicator |
|
: Red LED (illuminates when output is ON state) |
|
|
Stable operation indicator |
: Green LED illuminates |
|
|
|
|
|
|
under stable light intensity |
|
|
|
|
Sensitivity Setting |
: Automatic setting by Auto Tuning type |
|
|
|
Timer Function |
: Selectable; OFF Delay Timer 40ms fixed |
|
|
|
|
|
|
|
|
|
2 |
SENSOR UNIT MODEL : BF3-RX |
|
|
|
|
|
|
Light Source color |
|
: Red |
|
|
|
|
|
Power Source |
: 12 to 24VDC ± 10% |
|
|
|
|
Sensing Output |
: NPN Transistor - open collector |
|
|
|
|
|
Sink Current : Max 200mA Max. 30VDC |
|
|
|
|
|
With Reverse Power Polarity and Short Circuit Protection |
|
Response Time |
: Max. 1ms |
|
|
|
|
|
Sensitivity |
: Able to Adjust Sensitivity with high allowing |
|
|
|
|
by dual adjust (coarse adjustment, fine adjustment) |
|
Output operation |
|
: Light-ON/Dark-ON selector (by central wire) |
|
|
Explosion Proof |
: (Fibre part) |
|
|
|
|
|
|
|
|
|
|
|
|
3 |
SENSOR UNIT MODEL : BF5R-D1-N Dual Display |
|
|
|
|
|
Light Source color |
|
: Red LED (660nm), Pulse modulated light |
|
|
Power Source |
: 12 to 24VDC ± 10% |
|
|
|
|
Control Output |
: NPN open collector (Sink Current: Max. 100mA, |
|
|
|
|
Applied Voltage: Max. 24V, Residual voltage: Max. IV) |
|
Response Time |
: Ultra Fast: 50µs, Fast: 150µs, STD: 500µs, Long: 4ms |
|
|
Display |
: -Incident light level: Red, 4 digits, 7 segments |
|
|
|
|
-SV: Green, 4 digits, 7 segments |
|
|
|
|
|
-Main output indicator: Red LED |
|
|
|
Sensitivity Setting |
|
: Auto tuning mode, 1 point teaching |
|
|
|
|
|
2 point teaching, Positioning teaching |
|
|
|
Timer Functions |
: OFF, Off delay, On delay, One shot |
|
|
|
|
|
|
|
|
|
|
4 |
FIBRE UNIT MODEL: FT-420-10 |
|
|
|
|
|
|
Through Beam type Cable Length 2 meter, Threaded |
|
|
|
|
|
|
|
|
|
|
|
|
5 |
FIBRE UNIT MODEL: FD-620-10 |
|
|
|
|
|
|
Diffuse Type, Cable Length 2 meter, Threaded |
|
|
|
|
|
|
|
|
|
|
|
|
|
